Malabar 795 - Cylinder Assembly Parts Breakdown; Cylinder Assembly Diagram

79599 CYLINDER ASSEMBLY
FIGURE 2
CYLINDER
LOWER BEARING
PLUNGER
TRIPOD HEAD
UPPER BEARING
PLUNGER DIAPHRAGM
EXTENSION SCREW NUT
LOCKNUT ASSEMBLY
SHIP ADAPTER
RETAINING NUT
RETAINING RING
NO. QTY PART NO. DESCRIPTION
12 1 55925-446
13 1 55929-446
14 1 55932-266
15 1 55931-446
16 1 55925-438
17 1 55929-438
18 1 55928-700
19 1 371-014
20 1 331-001
21 1 331-002
22 1 79384
- 15 -
NO. QTY PART NO. DESCRIPTION
1 1 79503
2 1 79307
3 1 79306
4 1 79313
5 1 79619
6 1 79607
7 1 79316
8 1 79317
9 1 79386
10 1 79320
11 1 55924-825
♦ 13
♦ 12
2
18 6
O-RING
BACK-UP RING
O-RING
TEFLON O-RING W / GROOVE
O-RING
BACK-UP RING
RETAINING RING
ROLL PIN, 1/4 x 5/8 LG
SHSS, 1/2-20 x 1/2 LG
SHSS, 3/8-16 x 1/2 LG
EXTENSION SCREW
16 ♦
17 ♦
11 ♦
1
19
3
8
5
10
9
22
14 ♦
15 ♦
4
21
7
20
♦ PART OF REPAIR
PARTS KIT
