MODEL 795 JACK ASSEMBLY
- 14 -
BRACE
LOAD GAUGE KIT
RESERVOIR COVER
RESERVOIR GASKET
FILLER CAP w / DIPSTICK
DRAIN COCK VALVE
HHCS, 3/8-16 x 1 1/4 LG
HHCS, 1"-8 x 3 1/4 LG
FLAT WASHER, 3/8
SPLIT LOCKWASHER, 3/8
SPLIT LOCKWASHER, 1"
12 12 351-005
13 10 397-005
14 1 55994
15 1 79596
16 1 55991-14
17 1 79595
18 1 79225
19 1 79550
20 1 79567
21 1 79569
22 1 78567
NO. QTY PART NO. DESCRIPTION
FIGURE 1B
18
NO. QTY PART NO. DESCRIPTION
1 6 79552
2 1 79546
3 1 76346
4 1 76347
5 1 79562
6 1 424-005
7 6 321-008
8 12 321-002
9 6 361-001
10 6 363-003
11 12 363-008
22
21
HEX NUT, 1"-8
SELF TAPPING SCREW, #4
STICKER, FLUID
PLACARD, INSTRUCTION
PLACARD, TONNAGE, 100 TON
RAIN HAT (NOT SHOWN)
LEVEL ASSEMBLY
TRIPOD LEG
TRIPOD LEG w/ TOW BRKT
TRIPOD LEG w/ HANDLE HLDR
LADDER ASSEMBLY KIT
8
11
12
1
3
4
19
7
9
10
13
16
6
14
5
13
15
2
