Malabar 795 - Hand Pump Assembly Parts Breakdown; Hand Pump Assembly Diagram

79571-1 HAND PUMP ASSEMBLY
13 1 55925-220
14 1 55761
15 1 55745
16 2 55927-43
17 1 55739
18 3 372-001
19 1 370-001
20 1 MS51861-44C
21 3 373-001
22 1 79563
23 1 55762-7
NO. QTY PART NO. DESCRIPTION
PISTON
O-RING
BACK-UP RING
SCRAPER RING
RETAINING RING
PUMP BODY
O-RING
STEEL BALL, 3/8 DIA
STEEL BALL, 5/16 DIA
SPRING
O-RING
PUMP CYLINDER NUT
- 17 -
FIGURE 4
NO. QTY PART NO. DESCRIPTION
1 1 55738
2 1 55925-213
3 2 55922-18
4 1 55728
5 1 55729
6 1 55753
7 1 55925-211
8 1 412-001
9 1 412-002
10 1 55754
11 1 55925-021
12 1 79564
♦ 16
♦ 10
♦ 9
♦ 18
♦ 21
♦ 7
♦ 13
12
6
8 ♦
11 ♦
16 ♦
O-RING
FULCRUM
PUMP HANDLE CLAMP
RETAINING RING
LINK
COTTER PIN, 3/32 x 3/4 LG
QUICK RELEASE PIN, 1/4 DIA
SELF TAPPING SCREW, #10
FLAT HEAD PIN, 7/16 DIA
CYLINDER
PUMP HANDLE
18 ♦
21 ♦
2 ♦
17
22
1
3 ♦
20
14
♦ 4
♦ 5
♦ 18
♦ 21
15
19
3 ♦
♦ PART OF REPAIR PARTS KIT
23
