Malabar 95P10AR - Provision of Spares; Source of Spare Parts; Special Tools; Recommended Spare Parts Lists

Model: 95P10AR
Two Stage Hydraulic Aviation Floating Auto-Retract Axle Jack
S/N 263 and Up
12/2018 | Rev. 01 Page | 12
8.0 PROVISION OF SPARES
8.1 SOURCE OF SPARE PARTS
Spare parts may be obtained from the manufacturer:
Malabar International Telephone: (419) 866-6301 or 800-426-6301
1 Air Cargo Pkwy East E-mail: sales@malabar.com
Swanton, Ohio 43558 USA Website: www.malabar.com
8.2 SPECIAL TOOLS
Part Number
Description
Qty
880480
Spanner wrench, inner stop ring
1
880481
Spanner wrench, outer stop ring
1
86305T
Spanner wrench, diaphragm
1
880482
Lifting tool, extension screw
1
872845
Accumulator test gauge assembly, 0-300 psig
1
872839
Hose and test gauge assembly, 0-600 psig
1
8.3 RECOMMENDED SPARE PARTS LISTS
The following spare parts are recommended and available upon request. Reference the following page(s) for Replacement
Parts and Kits available.
Part Number
Description
Qty
95P10ARPK
Repair parts kit
1
492-012
Swivel Caster
2
492-002
Wheel
1
86399F
Valve block and hand pump assembly
1
55001
Fulcrum
2
886659
Plunger, 7/16 dia
1
886658
Body, 7/16 dia
1
886657
Plunger, 13/16 dia
1
886656
Body, 13/16 dia
1
86376
Pump handle
1
86392
Bumper
1
52526
Spring
1
86350
Yoke
1
86351
Yoke pin
1
86371
Cushion tube
1
86329
Hydraulic hose
1
873840
Hydraulic hose
1
86339
Breather cap & dipstick
1
85416
Release valve
1
424-004
Bypass valve
1
86367
Cross check valve
1
424-005
Drain cock valve
1
423-037
Relief valve
1
423-038
Deflector cap
1
86320A
Ship adapter
1
880410
Inner stop ring
1
880416
Outer stop ring
1
