2 INTRODUCTION
2.1 Technical Specications
Art.no. 27 003 86
Model AC011K-AE-25
Input
Power Supply Three-phase
Rated Voltage 400V AC
Rated Current 16A
Frequency 50/60Hz
Output
Output Voltage 400V AC
Maximum Current 16A
Output Power 11kW
User Interface
Charging Outlet Type 2 cable
Cable Length 4m
Housing Material Plastic PC 940
LED Indicator Green/Yellow/Red
RFID Reader Mifare ISO/IEC 14443A, 2 pcs
Start Mode Plug & Play / RFID card / APP
Communication
Communication WiFi 2.4G
Protocol OCPP1.6
Frequency Bandwidth
2400-2483.5MHz (WiFi)
13.553-13.567MHz (RFID)
Safety
Max RF Output Power <20dBm (-10dBW)
RCD 6mA DC
Ingress Protection IP65
Impact Protection IK10
Electrical Protection
Over current protection, Residual
current protection, Surge protec-
tion, Over/Under voltage protection,
Over/Under frequency protection,
Over temperature protection
Certication
EN/IEC 61851-1: 2017,
EN/IEC 61851-21-2: 2018,
EN/IEC 61000-6-1:2019
Environment
Installation Wall-/Floor mounting
Working Temperature - 30°C - +50°C
Working Humidity 5%~95%
Work Altitude <2000 m
Package
Product Dimension 328x181x87 mm (HxWxD)
Package Dimension 415x255x190 mm (LxWxH)
Net Weight 3.2 kg
Gross Weight 3.8 kg
