Malmet Bedpan / Urinal Bottle Washer Disinfector (ES-D)
Detergent Model with Hands Free Operation
Operation, Maintenance and Installation Manual
Issue 5 Page 36 June 23
WASH SYSTEM
Nozzles and Sprays
Flush nozzles
1 x Rotating 180° Nozzle
Main Chamber
2 x Fixed 60° Nozzles
Urine Bottle sprays
2 x Fixed 60° Nozzles
Cool Down sprays
1 x Fixed 60° Nozzle
Wash pump
Horizontal multistage
240V 1ph 3.1A
Detergent
Malmet specific (5Lt)
Detergent Concentrate
Caustic Alkaline
ARTG Class 1
Detergent pump
Self-priming peristaltic pump
240V 50Hz
PLUMBING
Soil line Connection
Type
‘S’ or ‘P’ Trap (6mm PE) 80°
Complies to
AS 2887-1993 (R2017)
& AS/NZS 3500.2:2018
Size
100mm ID
Backflow Prevention
Air Gap (RAG)
Water storage tank
AS 2845.2 - 2010
Cold water inlet Supply
Potable Water
(Final Rinse Water)
pH
6.5-8.5pH
Chloride
<30mg/L
Water Hardness
<2.5mmol/L
Water conductivity
<850 μS/cm
Temperature
15 – 25°C
Pressure
100 – 400kpa
Nominal Flow Rate
10L/Min
Solenoid Valve 1 in 2 out
240V - GB¾ male
WRAS Certified
Hose – valve to Cold Water Tank
S/Steel Braided
10mm
WRAS Certified
Hoses – Mains Water Supply to
Inlet Valve
S/Steel Braided
G¾ Hex Nut Each End
1.5M x 10mm
Certified to
AS/NZS 3499-2006 (R2016)
CONSTRUCTION MATERIALS
Materials
Frame
25 x 25 x 1.6 tube SS
Wash chamber
304 SS grade 4
Door
304 SS grade 4
External panels
304 SS grade 4
Water tank
316 SS grade 2B
Steam generator
316 SS grade 2B
Fasteners
304/316 SS
Principal Heavy Component
Main Wash Pump
11kg
TRANSPORTATION
HANDLING & STORAGE CONDITIONS
Fragile
Keep away from rain
Do not stack
Temperature
-5°C to +50°C
DIMENSIONS & WEIGHTS
Weights
Nett:
Operating:
Shipping:
Shipping (crated):
92 KG
122 kg
110 kg
151 kg
Dimensions (W x D x H)
595 x 660 x 1300 (mm)
710 x 790 x 1520 (mm)
710 x 790 x 1520 (mm)
Floor Loading at Each Support as
viewed from front of unit.
* Loadings are a guide only & will
vary between installations.
Front Left
Front Right
Rear Left
Rear Right
31 kg*
33 kg*
37 kg*
21kg*
