6.0 Technical Specifications
6.1 Power and Water Consumption
POWER AND WATER CONSUMPTION DATA
Model
Avg Cycles per/Hr
Avg Cycle min/sec
Avg kWh per cycle
CW Avg Lt per cycle
ES915S-D / ES915P-
D
20 Amp Model
11
5.3
0.300
36
ES935S-D / ES935P-
D
10 Amp Model
7.7
7.5
0.236
35.5
Note: Values may change due to operating and supply service conditions.
6.2 Device Specifications
ES-D915
Models
Electrical Rating
Volts
240V
APPROVALS
Phase / Hz
1 ph / 50 Hz
Amps
20 Amps
Heating Elements
Steam Generator
4500W 240V 3 x 6.25A Star
ES-D935
Models
Electrical Rating
Volts
240V
Phase / Hz
1 ph / 50 Hz
Amps
10 Amps
Heating Elements
Steam Generator
2200W 240V 3 x 3.05A Star
ELECTRICAL (Common components)
Element over temperature cut-out
Steam Generator
Capillary bulb thermal cut out
Manual reset 115°c 25A
Water tank
Capillary bulb thermal cut out
Manual reset 100°c 25A
Fuse: Transformer
Cylinder type 5 x 20mm
F3.15AL 250V
Fuse F1: Power supply PCB
Cylinder type
T315mA 250V
Door Actuator
Type LA12 Self-Locking
24VDC
Interlock Micro Switch
SPDT
240VAC 16A
PCB HARDWARE
PCB (Printed Circuit Boards)
Power supply board
CM00PS03
PCB module
CM00AV15
Interceptor PCB module
CM11IC03
Environment conditions
(Operating)
Location
Indoor Use
Altitude
<2000m
Temperature
+10°C to +25°C
Relative Humidity
+30% to 75%
Mains voltage fluctuations
240+10%
Overvoltage
Category II
Pollution
Degree II
WASH CHAMBER
Loading Configurations
2 x Urinal Bottles and One (1) of the following:
Bed Pan & Lid
Commode & Lid
Small Commode & Lid
Small Slipper Pan & Lid
Large Slipper Pan & Lid
Chamber Specifications
Material
1.2mm 304 Stainless Steel
Design Life
Minimum of 10,000 Cycles
Usable Volume
50 L
Total Volume
60 L
