Malone PROCUT 3000 MP - Transport into Working Position

Operator Manual –PROCUT 3000 MP
12
Transport into working position
The lower link arms will need to be around 80cm from the
ground.
Pull rope to release the locking lever
Lower the cutting frame to the ground level.
Release the locking lever rope
Set the settings on the tractor for the lifting ram into
floatation mode
