Operator Manual –PROCUT 3000 MP
15
Cutterbar
You will need a 8mm allen key to open the fill and
drain plugs on the cutter bar.
When draining the cutter bar oil from the bed
pan, place the cutter bar on a elevated height on a
secure stand at a tilt.
Remove the drain plug and empty the used oil from the cutter bar into a suitable
container.
After all of the oil has been drained, return the drain plug and ensure it has been
tightened to 3-3.5 kgm (30 - 35Nm).
Remove the stand and lower the cutter bar
frame to a level ground position.
Open the fill plug on top of the cutter bar and fill the cutter bar with the correct
amount and type of oil into the bed pan.
