Operator Manual –PROCUT 3000 MP
25
NO
PART NUMBER
QTY
DESCRIPTION
1
M12510
7
M10 WASHER (DIN 125A) BZP
2
M12512
1
M12 WASHER (DIN 125A) BZP
3
M98510
3
M10 NYLOCK NUT
4
M98512
1
M12 NYLOCK NUT
5
M9331030
5
M10 X 30MM DIN 933
6
M9331240
1
M12 X 40MM DIN 933
7
M69210820
2
M8 x 20 FLANGE BOLT (DIN 6921)
8
M14810850
2
Ø8 x 50 ROLL PIN (DIN 1481)
9
M14811060
1
Ø10 x 60 ROLL PIN (DIN 1481)
10
MPC20290
2
BUSH 455050
11
MPC20295
6
BUSH 405050
12
M0311180011
2
M8 HEX RIVET NUT
13
MPC20300
1
CIRCLIP, EXTERNAL Ø35 HEAVY DUTY
14
MCPM3C0018
1
LOCKING PLATE WASHER
15
MCPM3C0026
1
M10 WASHER ODØ40
16
MCPM3F0057
1
M10 WASHER ODØ58
17
MCPMC0006
1
FLOAT RAM CIRCLIP WASHER
18
MCPMC0007
1
HEIGHT INDICATOR
19
MCPMD0012
1
Ø40 PIN SHIM
20
MCPMF0014
1
PIVOT LIMIT - ARM
21
MCPMR0005
2
BULKHEAD CENTER STICKER
22
MCPMS0013
1
SWIVEL ARM PIN
23
MCPMS0014
2
BREAKAWAY PIN
24
MCPMS0015
1
ARM - UPPER
25
MCPMS0016
1
ARM - LOWER
26
MCPMS0022
1
RAM PIN 2
27
MCPMS0047
1
PIVOT PIN Ø40
28
MCPMS0050
1
LOWER ARM PIVOT PIN
29
M47135
1
Ø35 EXTERNAL CIRCLIP DIN 471
30
MDM3M0003
1
PANEL SPACER
31
MDMCM0037
1
NYLON STOPPER
32
MPC20095
3
M8 GREASE NIPPPLE – STRIAGHT
33
MPN25_01
2
Ø25 PIN CAP
34
MPN35_01
1
Ø35 PIN CAP
35
MPC20305
1
RUBBER DAMPER Ø50 X 75
36
MTD4M0109
1
ROLLER BUSHING
