Malone PROCUT 3000 MP - Page 27

Operator Manual –PROCUT 3000 MP
27
NO
PART NUMBER
QTY
DESCRIPTION
1
M12508
3
M8 WASHER (DIN 125A) BZP
2
M12510
27
M10 WASHER (DIN 125A) BZP
3
M98510
22
M10 NYLOCK NUT
4
M98512
8
M12 NYLOCK NUT
5
M98508
5
M8 NYLOCK NUT
6
M9331030
4
M10 X 30MM DIN 933
7
M9331040
1
M10 X 40MM DIN 933
8
M9331230
6
M12 X 30MM DIN 933
9
M9331240
2
M12 X 40MM DIN 933
10
M6030825
5
M8 X 25MM CUP BOLT
11
M6031025
21
M10 X 25MM CUP BOLT
12
M69210820
2
M8 x 20 FLANGE BOLT (DIN 6921)
13
MPC20310
4
M10 RIVET NUT
14
MCPM3C0007
1
BRACKET LH
15
MCPM3C0008
1
BRACKET RH
16
MCPM3C0009
1
COVER BRACKET
17
MCPM3P0010
1
GUARD SPACER
18
MCPMS0003
1
WELDED FRAME OVER BED
19
MCPMS0005
1
WELDED FRONT TUBULAR FRAME
20
MCPMS0012
1
TUBULAR FRAME 2
21
MCPMS0037
1
CUTTERBED FRAME ARM
22
MCPMS0039
1
END WING FRAME - 2 HINGE
23
MCPMS0049
1
3000 CUTTERBED FRAME BACK
24
MCPMS0051
1
REAR TUBULER FRAME CORNER
25
MCPMS0052
1
SIDE FRAME BUMPER BAR
26
MCPMS0053
1
FRONT FRAME BUMPER BAR 3000
27
MCPMT0003
1
FOLD OVER FRAME GAS RAM
28
MDM3M0003
6
PANEL SPACER
29
MPC20210
2
LINCHPIN 8 X 42
30
MTMM2036
2
PANEL SPACER
31
MCPMR0013
1
COVER – 3000MP
