Operator Manual –PROCUT 3000 MP
31
NO
PART NUMBER
QTY
DESCRIPTION
1
M0.420.7101.00
30
BOLT M10X20
2
M0.557.7101.00
5
COVER
3
M12510
4
M10 WASHER (DIN 125A) BZP
4
MNL12SP
4
M12 NORD-LOCK WASHER
5
MNLWM16
10
M16 NORD-LOCK WASHER
6
M98510
22
M10 NYLOCK NUT
7
M9331230
4
M12 X 30MM DIN 933
8
M9331630
4
M16 X 30MM DIN 933
9
M9331650
6
M16 X 50MM DIN 933
10
M9121030
4
M10 X 30 ALLEN HEAD BOLT
11
M9121032
6
M10 X 35 ALLEN HEAD BOLT
12
M79911030
16
M10 x 30 COUNTERSINK SCREW
13
M69210820
8
M8 x 20 FLANGE BOLT (DIN 6921)
14
M69211030
6
M10 x 30 FLANGE BOLT (DIN 6921)
15
M2.567.1310.00
7
S/GUARD
16
M2-567-7328-00
5
CONVEYOR QUICK FIT
17
M2-567-7423-00
1
CONVEYOR OUTER
18
M2-567-7427-00
1
CONVEYOR INNER
19
M.8.1.2.01531
10
BOLT M10X22 12.9 DCRT320
20
M9-312-388-00
1
GEARBOX SECONDARY 1:3
21
M9-567-007-00
1
COMPLETE CUTTERBED
22
MCPMC0001
1
DROP SHAFT MOUNTING PLATE
23
MCPMS0004
1
CP 3m CUTTERBAR MOUNTING TRAY
24
MCPMS0020
1
PTO GUARD HOLDER
25
MCPMS0036
2
DROP SHAFT COVER CURVED
26
M121.002.062.01
1
DROP SHAFT L=256MM
27
M952042
6
CUTTERBAR BLADE - RIGHT HAND
28
M952043
8
CUTTERBAR BLADE - LEFT HAND
29
MPC20310
7
QF SPRING 56 SERIES
