Operator Manual –PROCUT 3000 MP
33
3
M0.404.7131.00
1
PLUG 3/8” GAS
4
M0.404.7150.00
14
SPACER
5
M0.404.7159.00
1
PLUG 3/8” GAS
6
M0.567.0323.00
1
CUTTERBED+COVER
7
M12510
22
M10 N/LOCK NUT
8
M79911030
16
M10 X 30 COUNTERSINK SCREW
9
M8.1.3.01864
18
BOLT M10X20 DCRT320 10.9
10
M8.1.3.01873
14
BOLT M10X55 DCRT320 10.9
11
M8.2.3.02222
58
LOCKNUT M10 DIN 980
12
M8.3.3.00400
2
WASHER 3/8” GAS (17.13X22X2)
13
M8.3.7.02264
14
SPRING WASHER 10.2X22X1.6
14
M8.4.5.01205
2
SPRING PIN 10X12 D1481
