Malone PROCUT 3000 MP - Page 36

Operator Manual –PROCUT 3000 MP
36
2
M0.567.7204.00
FLANGE
NO
PART NUMBER
QTY
DESCRIPTION
1
MPC20315
4
GLACIER BEARING - 303440
2
MCPMR0005
1
LIFT RAM HOSE 1.7M
3
MCPMR0006
1
LIFT RAM HOSE - 2.1M
4
MCPMR0009
1
LIFT RAM
5
MPC20095
2
M8 GREASE NIPPPLE - STRIAGHT
6
MPC20320
2
3/8 MM 1.5MM RESTRICTOR
7
MPC20185
2
1/2 QUICK COUPLING
8
MPC20120
1
KENNIFIX GRIP (+)
9
MPC20125
1
KENNIFIX GRIP (-)
10
MPC20235
2
3/8 BONDED WASHER
11
MPC20385
1
LIFT RAM SEAL KIT
