Operator Manual –PROCUT 3000 MP
40
NO
PART
NUMBER
QTY
DESCRIPTION
1
M0.124.7101.00
1
PLATE
2
M0.244.7500.00
2
SHIM KI 40.3X51.5
3
M0.259.7510.00
1
SHIM 35.3X48.0X1
4
M0.267.7109.00
2
KEY FOR FREE WHEEL
5
M0.267.7110.00
2
SPRING
6
M0.267.7500.00
2
SHIM KIT 69.0X79.9
7
M0.312.0301.00
1
CASING T-312
8
M0.312.1320.00
1
COVER
9
M0.312.3005.00
1
SHAFT 1"3/8 Z6
10
M0.312.5200.00
1
PINION SHAFT Z12M4,58
11
M0.312.6007.00
1
CROWN WHEWEL Z369 M4.58
12
M1.312.1307.00
1
PROTECTION COVER
13
M8.0.1.00550
1
BALL BEARING 6208
14
M8.0.1.00871
1
BALL BEARING 6208
15
M8.0.9.00102
1
TAPERED ROLLER BEARING 32208
16
M8.0.9.00129
1
TAPERED ROLLER BEARING 30307
17
M8.1.1.00061
8
BOLT HH M10X25 UNI 5739 8.8
18
M8.1.1.00090
4
BOLT M12X25 UNI5739 8.8
19
M8.3.2.01236
8
BOLT WASHER 13X24X2.5
20
M8.5.1.00680
1
SNAP RING SHAFT D40 DIN471
21
M8.5.1.00712
1
SNAP RING SHAFT 42 UNI7435
22
M8.5.2.00030
2
SNAP RING HOLE D80 UNI 7437 DIN 472
23
M8.6.5.00006
4
PLUG EXTERNAL 3/8"GAS
24
M8.6.7.00161
1
BREATHER PLUG 3/8"GAS
25
M8.7.0.00790
1
CAP 80X0
26
M8.7.0.00975
1
CAP 100X10
27
M8.7.1.00315
1
DOUBLE LIP SEAL 35X80X10
28
M9020.307.101
1
DOUBLE LIP SEAL 40X80X10
