Operator Manual –PROCUT 3000 MP
42
NO
PART
NUMBER
QTY
DESCRIPTION
1
M0.124.7101.00
1
PLATE
2
M0.244.7500.00
2
SHIM KIT 40.3X51.5
3
M0.267.7500.00
2
SHIM KIT 69.0X79.9
4
M0.312.0301.00
1
CASING T-312
5
M0.312.1300.00
1
COVER
6
M0.312.2000.00
1
SHAFT 1"3/8 Z6
7
M0.312.5203.00
1
PINION SHAFT Z15 M5.68
8
M0.312.6000.00
1
CROWN WHEEL Z29 M5.68
9
M8.0.1.00550
1
BALL BEARING 6208
10
M8.0.1.00871
1
BALL BEARING 6208
11
M8.0.9.00024
1
TAPERED ROLLER BEARING 30208
12
M8.0.9.00102
1
TAPERED ROLLER BEARING 32208
13
M8.1.1.00061
8
BOLT HH M10X25 UNI5739 8.8
14
M8.4.1.00966
1
PARALLEL KEY B 12X8X35
15
M8.5.1.00680
1
SNAP RING SHAFT D40 DIN471
16
M8.5.2.00030
2
SNAP RING HOLE D80 UNI7437 DIN 471
17
M8.6.5.00006
5
PLUG EXTERNAL 3/8"GAS
18
M8.6.7.00161
1
BREATHER PLUG 3/8" GAS
19
M8.7.0.00790
1
CAP 80X0
20
M8.7.0.00975
1
CAP 100X10
21
M8.7.1.00748
2
DOUBLE LIP SEAL BASL 40X80X12 NBR
