M455 SMART ADJUSTABLE BED BASE
Electrical Layout and Battery
All electrical parts are preassembled and should not be
altered. For reference, here’s how things are set up.
Head Motor Input
Power Input
Foot Motor Input
Massage Motor Input
USB Input 1
USB Input 2
Sync Cable Input
Control Box
USB Locations
Power Supply Box
Backup Battery
Wall Plug Cord
