STARTING ENGINE
1. Fill fuel and chain oil tanks respectively, and tighten the caps securely.(F7)
2. Put the switch to "I" position.(F8)
3. While holding the throttle lever together with the throttle interlock, push in the side
throttle lock button and release the throttle lever to hold it at the starting position.(F9)
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lock button
(5) Throttle lever
(6) Throttle interlock
(7) Choke knob
4. Pull out the choke knob to the closed position.(F10)
When restarting immediately after stopping the engine, leave the choke knob at the open
position
5. While holding the saw unit securely on the ground, pull the starter rope vigorously. (F11)
DO not start the engine while hanging the chain saw with a hand. The saw chain may
touch your body. lt's very dangerous.
6. When engine has ignited first ,push in the choke knob and pull the starter again to start
the engine
7. Allow the engine to warm up with the throttle lever pulled slightly.
Keep clear of the saw chain as it will start rotating upon starting of engine.
CHECKING OIL SUPPLY
After starting the engine.. run the chain at medium speed and see if chain oil is scattered
off as shown in the figure. (F12)
Chain oil
The chain oil flow can be changed by inserting a screwdriver in the hole on bottom of the
clutch side. Adjust according to your work conditions (F13)
Adjuster
The oil tank should become nearly empty by the time fuel is used up. Be sure to refill the
oil tank every time when refueling the unit.
ADJUSTING CARBURETOR(F14)
The carburetor on your unit has been factory adjusted, but may require fine tuning due to
change in operating conditions. Before adjusting the carburetor, make sure that provided
