M5 – Eco CE
ENDING WORK AND CLEANING
In the case of ending the work or interruptions longer than 20 minutes (10
minutes if using rapid binding material) the machine must be turned off
and cleaned to avoid incrustations forming in the hoses and the mixing
chamber. The individual steps to do so are described in this chapter.
Cleaning as described here is a condition for long-lasting use of the
machine and without problems.
The parts of the machine that must not come into contact with
water (electrical box, cables and electrical connections) have
to be protected with impermeable material (e.g. Nylon)
before beginning cleaning.
Attention
!
The selector of the cell disc must be put in position „0“ to turn
the disc off at the end of the work.
If the hoses still contain material, continue to use
the sprayer until only water emerges.
It is then possible to close the air tap on the
sprayer.
Attention!
Closing the air tap stops the machine but does not turn it off!
The machine must be turned off, disconnecting the power by
removing the plug from the socket, before any intervention
(cleaning, maintenance, repair).
After having turned off the machine by
turning off the main switch (Pos. „0“), remove
the power supply plug.
Then open the side blocking device
(A) of
the inclinable flange and tilt the reduction
motor sideways.
Remove the shaft
(B) from the mixing chamber and insert cleaning device
(C).
After introducing the cleaning device rotate it slowly until it blocks and
close the pressure reduction motor again. Block the inclinable flange
again.
Note: Before closing the pressure reduction motor with the cleaning device
inserted, check that the joint
(1) is in the relative position with respect to
the device
(2).
A
Important
ATTENTION
ATTENTION
C
1
2
B
