Malvern Mastersizer 3000 Manual

Appendi x
109
Hydro series wet cell
Item Specification
Weight
2.46 kg
Dimensions
Width: 106 mm / Height: 273 mm / Depth: 227 mm
Liquid temperature range
(water jacket connections)
0 to 50°C
Maximum pressure
(water jacket connections)
0.5 bar g
Chemical compatibility
Although the Mastersizer 3000 has been manufactured from materials considered to give
the widest protection from chemical attack, it is important to check the chemical com-
patibility of a sample with any material with which it may come into contact.
!
Warning!
It is advisable that the chemical compatibility is checked against the materials
identified below before a sample is inserted. It is also recommended that a test
is performed on the material with the sample before more permanent usage is
undertaken.
Cleanliness and maintenance procedures necessary are described in Maintenance on
page1.
In normal operation the sample and dispersant should not come into contact with any
component of the optical bench (the sample path is contained within the dispersion unit
and the sample cell). However, if a sample pipe or o-ring seal should fail then sample or
dispersant may fall into the cell area of the optical bench.
Should a small leak occur the sample/dispersant may come into contact with the materials
described.
Hydro EV
Component Materials
Pump assembly
Stainless steel 316

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
