Hardware features
22
Hydro EV — basic operation
This section provides an overview of the working principles of the Hydro EV.
3
1
2
4
The Hydro EV uses a standard laboratory beaker [1] to hold the sample and dispersant
liquid.
Note: 600 ml and 1000 ml beakers are recommended.
The pump head [2] tilts back allowing the insertion of a beaker that contains dispersant.
The pump head is then tilted forward, lowering the pump arm into the beaker. If the
pump head is raised at any time, the pump will automatically stop.
The pump is controlled by the software, circulating dispersant from the unit to the wet
cell [3] located in the optical bench. Sample must be added manually to the beaker.
A stirrer [4] agitates the sample to prevent settling.
Use of the ultrasonic transducer can also aid sample dispersion and remove bubbles.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
