Hardware features
38
The complete cell is inserted into the cell bay of the optical unit. With the cell in position,
a motor within the cell rotates the stirrer bar that continually circulates the dispersant
around the cuvette to make sure it is adequately dispersed prior to a measurement. The
stirrer speed is controlled using the Mastersizer software or front panel dial. Refer to the
Mastersizer 3000 User Manual for advice on sample addition.
Once measured with the Mastersizer optical unit, the sample can be disposed off. First
remove the SV cell, then remove the cuvette and dispose of the sample appropriately.
Note: As the Hydro SV incorporates a magnetic stirrer for the dispersion of the
sample, it is recommended that the Mastersizer 3000 is not used anywhere
near external magnetic fields, or used where stationary magnets may impact.
These may affect the effectiveness of the stirrer bar sample dispersion.
Recommended sample criteria
l Size typically less than 200 µm
(sample and dispersant dependent)
l Non-magnetic samples only
l Non-abrasive samples

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
