Hardware features
65
1. Power cable to Pump
2. Pumphead
3. Dispersant source
4. Dispersant inlet
5. Auxiliary control cable
6. Retaining clip
Refer to the Connecting the Dispersion units section for connection of the Hydro LV and
MV to the Optical unit.
Pump setup
The information below on setting the pump is taken from the pump user manual. Refer
to this manual for complete information about the pump operation.
1. The pump must be set for the voltage specific to the country it is installed into. Set
the mains voltage selector at the rear of unit to the correct voltage for the country
you are in. Refer to the Peristaltic pump user manual.
2.
Connect the power cable [1] into the rear of the pump.
3.
Connect the auxiliary control cable [2] from the dispersant unit into the rear of the
pump.
The pump must be set for Analogue-Automatic operation mode using the control cable
and Malvern software (Auto restart mode). In this mode the pump will automatically
start in automatic mode when turned on.
To do this:
1. Turn pump off using mains switch on rear of unit.
2.
Hold down the Start button on the front of the pump, and turn the mains switch
on. An exclamation mark ( ! ) is shown on the screen.
3.
Put pump into Analogue-Automatic mode.
Press Mode until ANA is displayed on screen.The word Auto is shown in the
corner to indicate that the pump is in analogue and automatic mode.
4. The pump is now set.
It will now always restart in Analogue-Automatic mode whenever the power is
connected.
