Chapter 3 Software features
Page 3-6 MAN 0386
Writing an SOP for the dispersion unit
An SOP can be configured to control all settings for the dispersion unit automati-
cally. When an SOP is run, the software will (depending on how the SOP has been
set up) automatically set the air pressure and feed rates to a pre-defined setting and
run through a measurement sequence. The SOP will even report if the wrong cell
or dispersion unit is fitted.
The SOP Wizard is described in full in the main User Manual. There are ten
dialogues in all but here we just describe those which have parameters specific to
the Scirocco 2000. These are the Sampler Selection, Sampler Settings and
Measurement Cycles dialogues.
Ensure that all systems an SOP is distributed to have the dispersion unit connected.
Sampler Selection dialogue
The Sampler Selection dialogue is shown below.
ill 7767
1
