Mamiya 7 II - Viewfinder Display

Nomenclature Parts
Viewfinder display
Bright field of view frame with 80mm F4 standard lens
Long time exposure
(under-exposure
[Blinks])
Bulb
Red warning lamp
The red lamp illuminates when
• the shutter is not cocked
• the light shield curtain is closed
• the film is not loaded
• the lens is not attached
• the battery power is weakening : The lamp blinks.
7
Double-image
superimposing
range finder zone
Over-exposure indicator
