Technical information
24
Gas mixer (7)
1234 5 6
7DC
AB
E
2339
1 Setting screw for regulating A Air inlet from air cleaner
bypass gas for idling B Outlet of gas/air mixture to
2 Gas annulus engine
3 Gas passage C Throttle valve casing
4 Metal hose D Venturi
5 Setting screw for regulating max E Gas inlet from gas
permissible gas flow regulating station
6 Throttle valve for regulating engine output
7 Bulb
