Technical information
22
Gas supply system
Note:
The gas supply system is not included in our scope of supply. Metal hose and zero-pres-
sure regulator, however, can be supplied at request.
Always proceed according to Manufacturer’s Operating Instructions when commission-
ing, operating and servicing the gas supply system.
A typical gas supply system which meets all requirements for trouble-free operation of
the engine is described below.
Any manipulations or adjustments of the gas system should only be carried out by
qualified personnel.
12
345
6
7
8
1879
1 Isolating cock
2 Gauge connection
3 Zero pressure regulator
4 3/2-way solenoid valve
5 Connection for air cleaner compensation
6 Idling adjustment screw
7 Gas mixer
8 Metal hose
