Manaras Opera-H - Page 20

20
8.4.3 Pull Cord & Key Switch
Figure 34 - PULLCORD 001 / 003 / 004 / 007
Figure 35 - KEYSWITCH 010 / 015
Figure 36 - KEYSWITCH 019
For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information
3
8
4
O/C
For OPEN only
N.O.
COM
COM
OR (OU)
(Seulement pour OUVERTURE)
NO
COM
NO
COM
CLOSE
OPEN
COM
5
4
3
Place a jumper between
#8 & #9 on the board
(Installer un cavalier entre
#8 & #9 sur la plaquette)
NO
COM
NO
COM
2
COM
STOP
3
4
5
CLOSE
OPEN
STOP BUTTON
2-Position Key Switch 2-Position Key Switch & Stop Button
Recommendation: Put Control Board on C2
or E2 Mode (constant-pressure-to-close)
