4.3 Opera-J
Table 15 - Opera-J Replacement Components
No Qty Description
Manaras-Opera
Part #
No Qty Description
Manaras-Opera
Part #
1
2 5/8-18 HEX JAM NUT ZP NUT013
4
1 PULLEY 7" x 5/8" 5L/B PULLEY020
2
1 CL.PAD 5/8x4x0.125" CLUTCHPAD005
5
1 STD SINGLE CUT-OFF SWITCH LIMIT020
3
1 OPERA CLUTCHPLATE CLUTCHPLATE006
1 CLUTCH SHAFT KIT (OPJ) MOUNSHAFT020
For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information
Figure 47 - Opera-J Mechanical Exploded View
