M&C PSS Series - 23 Spare Parts List

44 PSS-5C | 1.02.02 www.mc-techgroup.com
23 Spare parts list
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
For spare parts of components which are not presented in the following list please see the specific
instruction manuals or leaflets added in the appendix.
Portable Conditioning System PSS-5C, PSS-5/2C, PSS-5/3
(C) consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity
PSS-5...
being in operation
[years]
Part No.
Description
C/R/S
1
2
3
Fine filter FP-2T:
90F0002
Filter element F-2T, PTFE, 2 µm
C
6
12
20
90F0040
Viton O-ring, 26 for FP-
R
1
1
1
90F0056
PVDF filter element clamp F-P
S
-
-
1
90F0012
Filter body F-120G of glass
R
1
1
1
Fine filter FP-2T with Option LA1S: 4 (see Figure 8)
90F0015
Filter body F-120G-D of glass
with GL 25 condensate connection thread
R
1
1
1
90F0020
Union nut GL 25
R
1
1
1
90F0025
PTFE sealing ring GL 25-12 mm Ø
R
1
1
1
Peristaltic pump SR25.2-W:
90P1007
SR25 pump hose with PVDF tube connectors
DN 4/6 mm
C
1
2
4
Diaphragm pump type N3 KPE/KP18; N5 KPE/KP18
90P2100
Square cap type D3, 1/8“i for N3/N5 KPE/KP18
Material: PVDF
S
-
-
1
90P2120
Diaphragm type S3, for N3/N5 KPE/KP18,
Material: Viton, PTFE coated
C
1
2
3
90P2115
Sealing ring type O3, for N3/N5 KPE/KP18,
1 piece, Material: Viton (2 pc. required)
C
2
4
6
90P2110
Valve plate type V3, for N3/N5 KPE/KP18,
1 piece, Material: Viton (2 pc. required)
C
2
4
6
90P2105
Intermediate plate type Z3, for N3/N5 PE/KP18
Material: PVDF
S
-
-
1
Diaphragm pump type N9 KPE/KP18
90P2200
Square cap type D9, 1/8“i for N9 KPE/KP18,
Material: PVDF
S
-
-
1
90P2220
Diaphragm type S9, for N9 KPE/KP18,
Material: Viton, PTFE coated
C
1
2
3
90P2211
Valve plate with seal for N9 KPE, 1 pc.,
material: Viton. (2 pcs./pump)
C
2
4
6
