M&C PSS Series - Type Plate and Labels on the Device; Figure 1 Type Plate; Figure 2 Labelling of the Connections

8 PSS-5C | 1.02.02 www.mc-techgroup.com
Wear protective clothes!
Working with chemicals, sharp objects or extreme
ly high
temperatures requires wearing protective clothes.
5.1 Type plate and labels on the device
A type plate, an information label and a warning label are located on the device.
The type plate contains the product name, the serial number including explanation, electrical connection
data and the manufacturer's address.
1 Serial number
4 S/N: digits 3+4: Month 01
2 Electrical connection data
5 S/N digits 5 to 8: consecutive number
3 S/N: digits 1+2: Year 2018
Figure 1 Type plate
The position of the electrical connections and gas connections are explained on the label below the
connections on the case side.
Figure 2 Labelling of the connections
