2-58
LASHING DOWN THE LIFTING PLATFORM
- Set chocks on the truck bed on each of the lifting platform’s tyres, front and rear 2 (Fig.
E).
- Also set chocks on the truck bed on the inside and the outside of each tyre 3 (Fig. D).
- Lash the lifting platform down on the truck bed with sufficiently strong ropes 4 (Fig. E),
to the front and the rear, passing the ropes through the slinging eyes 5 (Figs. D and F).
D
F
E
5
5
5
5
33
4
2
5
5
647414 EN (27/05/2015)
