2-48
42 - BUZZER UNDER THE BASKET CONSOLE
- This buzzer is activated when the machine reaches the maximum authorised level of
tilt or is overloaded.
- Sounding intermittently: the machine is tilting. When the authorised tilt limit threshold
is crossed, all movements are blocked except for lowering the arms to enable return to
an acceptable level.
- Sound continuously: the machine is overloaded. When the platform is overloaded,
all movements are blocked. It is essential to unburden the machine so that you can
manoeuvre.
43 - SAFETY HARNESS HOOK-UP POINTS
- These fittings are to be used for fastening the harnesses when operators are in the
basket.
44 - SAFETY RAIL
- You must hold the rail to climb into the basket so that the rail does not fall back as the
operator climbs in.
Do not hold the safety rail with a collar or string.
45 - GENERATOR ACTIVATION BUTTON (OPTION)
- See the “DESCRIPTION AND USE OF THE OPTIONS” Section, page 2-61
42
43
43
647414 EN (27/05/2015)
