2-16
CHARACTERISTICS OF 160 ATJ E3 - 160 ATJ E3 RC - 160 ATJS E3
HYDRAULIC CIRCUIT
UNIT
160 ATJ E3 160 ATJS E3 160 ATJ E3
Wheel
18” TOL ±
Auxiliary hydraulic pump
Type fixed cubic capacity BOSCH
Cubic capacity Cm3 19 -
Max flow rate, unladen l/min 57 -
Max permanent service pressure bar 230 210 230 5
Filtration
Return μm - -
Suction μm 100 (ß10) -
Pressure μm 10 -
ELECTRICAL CIRCUIT
UNIT
160 ATJ E3 160 ATJS E3 160 ATJ E3
Wheel
18” TOL ±
Battery
C5 capacity Ah 105 -
Nominal voltage V 12 -
Type Starting -
Alternator
Type --
Intensity A 40 -
Voltage V 12 -
Starter
Type --
Power Kw - -
Voltage V 12 -
EMERGENCY PUMP
UNIT
160 ATJ E3 160 ATJS E3 160 ATJ E3
Wheel
18” TOL ±
Type Electric -
Cubic capacity Cm3 2,0 -
Power Kw 1,3 -
Voltage V 12 -
Intensity at 150 bars A - -
Integral thermal cut-off YES
S2 min 6.2 min at 100 b -
S3 % 10.3 % at 100 b -
647414 EN (27/05/2015)
