Base module control unit Measure using the calibrator Multimeter
Connector PIN Wire N° Signal Menu Description Not activated Activated Not activated Activated
D-OUT
1
262
Tank return
NOT MEASURABLE
2 227 Arm 1/2 - Lowered NOT MEASURABLE
3 239 Arm 1/2 - Raised NOT MEASURABLE
4
226
Arm 3 Lowered
NOT MEASURABLE
5 238 Arm 3 - Raised NOT MEASURABLE
6 224 Jib - down NOT MEASURABLE
7
236
Jib - up
NOT MEASURABLE
8 221 Turret - Left Rotation NOT MEASURABLE
9 225 Telescope - Extended NOT MEASURABLE
10
228
Turret - Right Rotation
NOT MEASURABLE
11 219 JIB - Left Rotation NOT MEASURABLE
12 222 Basket - Left Rotation NOT MEASURABLE
13
237
Telescope - Extended
NOT MEASURABLE
14 223 Compensation - Lowered NOT MEASURABLE
15 234 Steering - Left NOT MEASURABLE
16
229
Steering - Right
NOT MEASURABLE
17 220 JIB - Right Rotation NOT MEASURABLE
18 230 Basket - Right Rotation NOT MEASURABLE
19
217
Horn
NOT MEASURABLE
20 218 Flashing Lights NOT MEASURABLE
21 231 Compensation - Raised NOT MEASURABLE
22
233
Brake
NOT MEASURABLE
23 Free NOT MEASURABLE
24 235 Pump NOT MEASURABLE
NOTE: When powered on, the LED ashes once, then switches on or remains o depending on the
results of the test phase.
- The operation of the base and basket fail-safes is checked using input 2.4.5 (680.3.4 VARIABLE SPEED
CONTROLLERS  CONTROL AND SETTINGS, 5 115)
- To check the inputs on the base control unit, it is imperative that the fail-safe button is pressed, then
proceed by holding down the movement selector.
