Menu Pump Upper Box Test Test Hydraulic Functions Basket Codes Mini display Maxi display Pitch Type
2.4.1 Y axis Joystick % Joystick - Y-axis % 0 1 0.01 range
2.4.2 Y axis Joystick Voltage Joystick - Y-Axis Voltage 0.0 V 5.0 V 0.02 V range
2.4.3
X axis Joystick %
Joystick - X-axis %
0
1
0.01
range
2.4.4 X axis Joystick Voltage Joystick - X-Axis Voltage 0.0 V 5.0 V 0.02 V range
2.4.5 Deadman Joystick - Deadman pedal Open Closed – Switch
2.4.8
Jib extension
Jib detection
Open
Closed
–
Switch
2.4.9 Cage over Overload detection no. 1 Open Closed – Switch
2.4.10 Traction select Travel selection Open Closed – Switch
2.4.11
Boom 1 Select
Select arm 1/2
Open
Closed
–
Switch
2.4.12 Boom 2 Select Select arm 3 Open Closed – Switch
2.4.13 Jib select Jib selection Open Closed – Switch
2.4.14 Tele Select Telescope selection Open Closed – Switch
2.4.15 Slew Select Turret rotation selection Open Closed – Switch
2.4.16
Cage Level Select
Compensation selection
Open
Closed
–
Switch
2.4.17 Cage Rotate Basket rotation selection Open Closed – Switch
Menu Pump Upper Box Test Test Hydraulic Functions Basket Codes Mini display Maxi display Pitch Type
2.6.1 Boom 1 Up Arm 1 Lifting Control Open Closed – Switch
2.6.2
Boom 1 Down
Arm 1 Lowering Control
Open
Closed
–
Switch
2.6.3 Boom 2 Up Arm 2 Lifting Control Open Closed – Switch
2.6.4 Boom 2 Down Arm 2 Lowering Control Open Closed – Switch
2.6.5
Jib Up
Control jib raising
Open
Closed
–
Switch
2.6.6 Jib Down Control jib lowering Open Closed – Switch
2.6.7 Tele In Control telescope retraction Open Closed – Switch
2.6.8
Tele Out
Control telescope extension
Open
Closed
–
Switch
2.6.9 Slew Left Control turret right rotation Open Closed – Switch
2.6.10 Slew Right Control turret left rotation Open Closed – Switch
2.6.11
Lower Box select
Selection BASE controls
Open
Closed
–
Switch
2.6.12 Cage Level Forward Control forward compensation selection Open Closed – Switch
2.6.13
Cage Level Reverse
Control backwards compensation selection
Open
Closed
–
Switch
2.6.14 Cage Rotate Left Control turret left rotation Open Closed – Switch
2.6.15 Cage Rotate Right Control turret right rotation Open Closed – Switch
