COMPONANTS OF THE HYDRAULIC LAYOUT
20 Hydro accumulator 75 ml
Pressure controller
18 Balancing valve 80 b
17 Balancing valve 180 b
16 Pressure reducer
b 2
Valve
51
14 Main pressure restrictor 160 b
13 Pressure reducer
12 Rotating JIB (Option)
11 Compensation / Tilt
10 Pendular arm
9 Telescope
8 Arm 3
7 Arms 1-2
6 Basket rotation
5 Steering
4 Turret rotation
3 Brakes
2 Brakes
1 Safety valve
AETJ
Standard
Taring
No. Function
NOTE : Delivery of the block with the adjustment
21 Pressure restrictor 150 b
This diagram relates to lifting platforms :
- 150 AETJC - 150 AETJC 3D
- AETJ 43 - AETJ 43 3D
- 150 AETJL
- 170 AETJL - AETJ 49
AETJ standard
80 b
Raising
Lowering
Raising
Lowering
Extended
Retracted
Raising
Lowering
Boost
Tilt
Right
Left
Transport
Position
Stop
Stop + steering
translation
translation + steering
Raising 3
Telescope
Pendular arm
Stop
Stop + steering
translation
translation + steering
Turret Rotation
Raising 1-2
Basket Rotation
Tilt
Jib Rotation (option)
Work
Position
Right
Right
Left
Left
ACTIVATION TABLE FOR THE ELECTRO-VALVES
ACCORDING TO THE DESIRED MOVEMENT
E or E
E or E
E or E
E or E
Please refer to the hydraulic layout to match the electro-valve numbers and their location on the platform
E : Excited
20 b
b52
