25
CIRCUS EXPERT SERVICE MANUAL
4
5
6
Insert the ABS+ compression damper
into the damper leg. Ensure the damper
is set in the unlocked position when
installing.
Install the ABS+ damper using a 24mm
socket and torque wrench, tighten the
damper to 60–80 in lbs [6.8–9.0 NM].
Install springs and ball bearings into
ABS+ top cap. A small dab of grease on
top of the spring can help hold the ball
bearings in place.
COMPRESSION DAMPER INSTALL
