Manitou MLA 628 -120 LSU 3-E2 Series - Page 56

2 - 102 - 10
V
V
OO
KK
AA
1200 mm (47.2 in)1200 mm (47.2 in)
BB
2500 mm (98.4 in)2500 mm (98.4 in)
CC
1419 mm (55.9 in)1419 mm (55.9 in)
C1C1
1821 mm (71.7 in)1821 mm (71.7 in)
DD
5394 mm (212.4 in)5394 mm (212.4 in)
EE
6594 mm (259.6 in)6594 mm (259.6 in)
FF 1770 mm (69.7 in)1770 mm (69.7 in)
F1F1
1770 mm (69.7 in)1770 mm (69.7 in)
GG
455 mm (17.9 in)455 mm (17.9 in)
G1G1
390 mm (15.4 in)390 mm (15.4 in)
G2G2
460 mm (18.1 in)460 mm (18.1 in)
II
1475 mm (58.1 in)1475 mm (58.1 in)
KK
1260 mm (49.6 in)1260 mm (49.6 in)
LL
45 mm (1.8 in)45 mm (1.8 in)
NN
2050 mm (80.7 in)2050 mm (80.7 in)
OO
125 mm (4.9 in)125 mm (4.9 in)
P2P2
42 °42 °
P3P3
27 °27 °
RR
4005 mm (157.7 in)4005 mm (157.7 in)
UU 44 °44 °
U1U1
2645 mm (104.1 in)2645 mm (104.1 in)
U2U2
2860 mm (112.6 in)2860 mm (112.6 in)
VV
4500 mm (177.2 in)4500 mm (177.2 in)
V1V1
2005 mm (78.9 in)2005 mm (78.9 in)
V2V2
4233 mm (166.7 in)4233 mm (166.7 in)
WW
2225 mm (87.6 in)2225 mm (87.6 in)
YY
10 °10 °
ZZ
151 °151 °

