2 - 45
11 - AD A P TAT I O N "I N C H I N G " H Y D R A U L I C
TRANSMISSION CUT-OFF
This pedal operates in two steps :
- First, the pedal acts upon a hydraulic valve which progressively cuts off the
hydrostatic transmission so as to carry out a slow approach with all the I.C.
engine output.
- Then, the pedal acts upon a hydraulic valve which progressively makes the
pressure in the brakes drop so as to immobilize the lift truck.
12 - FOOT ADAPTATION GEAR REVERSER
The lift truck must be stationary when operating the forward / reverse lever.
FORWARD : Press the pedal 1 on the right.
REVERSE : Press the pedal 2 on the left.
NEUTRAL : To start the lift truck, do not press the reverser pedals.
