2-8
I.C. ENGINE
Type PERKINS 1104C-44 RE38454
Fuel Diesel
Number of cylinders 4 in line
Suction Natural
Injection system Direct
Ignition sequence 1.3.4.2
Capacity cm3 4400
Bore and stroke mm 105 x 127
Compression ratio 19,3/1
Nominal rating loaded rpm 2200
Rating slow unladen rpm 850
Max. rating unladen rpm 2350
Power ISO/TR 14396 cv- kW 84 - 61,5
Power SAE J 1995 cv- kW 84 - 61,5
Maximum torque ISO/TR 14396 Nm 308 to 1400 rpm
Air cleaner μm 3
Type of cooling By water
Fan Puller
TRANSMISSION
Gear box DANA
Type Mechanical
Forward/reverse selector Electro-hydraulic
Torque conver ter DANA
Number of forward speeds 4
Number of reverse speeds 4
Angle gear box -
Front axle DANA
Differential Without locking
Rear axle DANA
Differential Without locking
Drive wheels 4RM Permanent
Switch for 2/4 drive wheels No
Front tyres MICHELIN
Size 400/80-24 162A8 TUBELESS
Pressure bar 4,1
Rear tyres MICHELIN
Size 400/80-24 162A8 TUBELESS
Pressure bar 4,1
ELECTRIC CIRCUIT
Battery (according to installation)
12 V - 110 Ah - 750 A EN
12 V - 180 Ah - 1000 A EN
Alternator 12 V - 85 A
Type DENSO A115i
Starter 12 V - 3 kW
Type DENSO E95RL
BRAKE CIRCUIT
Service brake Hydraulic power brake
Type of brake Multidisk brake immersed in oil
Type of control Foot-operated for the front and rear axles
Parking brake Low pressure brake
Type of brake Disk on gear-box output
Type of control Electro-hydraulic
SOUND AND VIBRATION
Level of sound pressure in the driver’s cab LpA
(according to standard NF EN 12053)
dB 83 (cab closed)
Level of sound power ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB 105 (ensured)
Average weighted acceleration on driver’s body
(according to standard NF EN 13059)
m/s2 1,765
The average weighted acceleration transmitted to the driver’s hand/arm system
(according to standard ISO 5349-2)
m/s2 < 2,5
CHARACTERISTICS
MT 1436 R PRIVILEGE
