Manitou MT 1840 R PRIVILEGE User Manual

2-9
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (jib retracted)
Unladen lifting s - m/mn 12,5 - 29,9
Laden lifting s - m/mn 12,7 - 29,4
Unladen lowering s - m/mn 13,5 - 27,7
Laden lowering s - m/mn 13,2 - 28,3
Telescoping motions (jib raised)
Unladen extending s - m/mn 26,4 - 16,6
Laden extending s - m/mn 27,5 - 17,3
Unladen retracting s - m/mn 14,5 - 31,4
Laden retracting s - m/mn 14 - 32,6
Tilting movements
Unladen digging s - °/s 4,1 - 30,7
Forward tilting unladen s - °/s 3,5 - 36
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground
(except particular conditions)
Front unladen 1 km/h 5,1
2 km/h 8,0
3 km/h 15,0
4 km/h 25,5
Rear unladen 1 km/h 5,1
2 km/h 8,0
3 km/h 15,0
4 km/h 25,5
Standard attachment TFF 45 MT1040
Weight with forks kg 224
Weight of forks (each one) kg 73
Rated capacity with standard attachment kg 3600
Tipping load at maximum reach on stabilisers kg 1305
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 13520
Lift truck weight without attachment kg 9400
Lift truck weight with standard attachment
Unladen kg 9770
At rated load kg 13770
Weight per axle with standard attachment (transport position)
Front unladen kg 5490
Rear unladen kg 4280
Front rated load kg 12130
Rear rated load kg 1240
Weight per axle with standard attachment (jib extended)
Front rated load kg forward tip over
Rear rated load kg forward tip over
Contact pressure on the ground for the whole surface of each stabilizer
at maximum load when tilting
kg/cm2 5,6
Drag strain on the coupling hook
Unladen (sliding) daN 7180
At rated load (transmission setting) daN 8400
Pull strain with open carrier
(according to standard ISO 8313) daN 8050
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear pump with flow divider on 1st casing
1st casing
Capacity cm3 44
Max. rating capacity unladen l/mn 103
Flow rate at 1600 rpm l/mn 70
Filtration
Return μm 16
Suction μm 135
Maximum service pressure bar 270
Telescoping circuit bar 180 / 270
Lifting circuit bar 210 / 270
Tilt circuit bar 280 / 200
Stabilizers Circuit bar 270
Tilting corrector circuit bar 270
Attachment circuit bar 270
Steering circuit bar 140
