Manitowoc CNF0201 - Component Specifications; Main Fuse; ICE;OFF;CLEAN Toggle Switch; Low Temperature Thermostat

Part Number 000015432 Rev02 5/21 105
MAIN FUSE
The main fuse is 250 Volt, 10 amp.
ICE/OFF/CLEAN TOGGLE SWITCH
Single-pole, double-throw switch. The switch is connected
into a varying low D.C. voltage circuit.
LOW TEMPERATURE THERMOSTAT
Specifications
Cut-Out Cut-In
-25°C (-13°F) 4°C (25°F)
LOW PRESSURE SWITCH
Specifications
Cut-Out Cut-In
Current Production &
Replacement Part
17 psig ±5 35 psig ±7
HIGH PRESSURE CUTOUT (HPCO) CONTROL
Cut-Out Cut-In
450 psig ±10
(3103 kPa ±69)
31 bar ±.69
Automatic Reset
(Must be below 300 psig
[2068 kPa 20.68 bar] to reset.)
FAN CYCLE CONTROL
Specifications
Cut-In (Close) Cut-Out (Open)
250 psig ±5 200 psig ±5
Component Specifications
