OPERATING CONTROLS AND PROCEDURES GRT8100 OPERATOR MANUAL
3-24 Published 3-25-2020, Control # 595-10
In the following example, Modes A (2) and B (3) are disabled
and grayed out. Mode X (4) is active. Any automatic mode
combination allowed.
RCL Display Setup Screens
Telescoping Mode change requires rigging code
confirmation. 4-digit rigging code is the same for all
telescoping modes.
All Modes Available and in Sequence
Select Telescoping Mode (load chart) on RCL. Selected
mode (1) displays on screen.
Telescope Mode/Load Chart (2) shows all modes enabled
and in sequence.
Last confirmed telescoping mode (3) shown in status bar.
NOTE: RCL override does not effect Telescoping Mode.
All Modes Enabled - A & B Out of Sequence
Select Telescoping Mode (load chart) on RCL. Selected
mode displays in status bar (1).
Mode selection is grayed out (2) and not available if out of
sequence or load chart not available.
Last confirmed telescoping mode (3) shown in status bar.
A & B Modes Disabled - X Mode In Sequence
Select Telescoping Mode (load chart) on RCL. Selected
mode displays on screen(1).
A and B modes disabled. Telescope Mode/Load Chart (2)
does not display disabled modes.
Last confirmed telescoping mode (3) shown in status bar.
1
4 32
1
2
3
3
2
1
2
1
3
