A_GC_SM_HDGASCOUNTERSERV_GT-UT-SERIES (Rev 1) Page 7
Technical Data
Model Information
Garland Models US Range Models Model Information
GTOG24-SU4 UTOG24-SU4 Gas, Four Open Burners Step Up, 24” Wide
GTOG36-SU6 UTOG36-SU6 Gas, Six Open Burners Step Up, 36” Wide
GTOG48-SU8 UTOG48-SU8 Gas, Eight Open Burners Step Up, 48” Wide
Line Ratings
Garland US Range Natural Gas @ 4.5”WC
Manifold Pressure
L. Propane Gas @ 10”WC
Manifold Pressure
Models Models BTU/h Injectors BTU/h Injectors
GTOG24-SU4 UTOG24-SU4 120,000 #36 108,000 #1.6mm
GTOG36-SU6 UTOG36-SU6 180,000 #36 162,000 #1.6mm
GTOG48-SU8 UTOG48-SU8 240,000 #36 216,000 #1.6mm
For use with Natural or Propane gas only.
Gas input ratings shown for installation up to 2000 ft (610m) above sea level.
Supply Operating Pressure
Natural Gas Propane Gas
“WC MBar “WC MBar
7 17.5 11 27.5
GTOG24-SU4 Shown
Open Top Burner Step-Up Models
