A_GC_SM_HDGASCOUNTERSERV_GT-UT-SERIES (Rev 1)Page 6
Technical Data
Model Information
Garland Models US Range Models Model Information
GTOG12-2 UTOG12-2 Gas, Two Open Burners, 12” Wide
GTOG24-4 UTOG24-4 Gas, Four Open Burners, 24” Wide
GTOG36-6 UTOG36-6 Gas, Six Open Burners, 36” Wide
GTOG48-8 UTOG48-8 Gas, Eight Open Burners, 48” Wide
Line Ratings
Garland US Range Natural Gas @ 4.5”WC
Manifold Pressure
L. Propane Gas @ 10”WC
Manifold Pressure
Models Models BTU/h Injectors BTU/h Injectors
GTOG12-2 UTOG12-2 60,000 #36 52,000 #53
GTOG24-4 UTOG24-4 120,000 #36 104,000 #53
GTOG36-6 UTOG36-6 180,000 #36 156,000 #53
GTOG48-8 UTOG48-8 240,000 #36 208,000 #53
For use with Natural or Propane gas only.
Gas input ratings shown for installation up to 2000 ft (610m) above sea level.
Supply Operating Pressure
Natural Gas Propane Gas
“WC MBar “WC MBar
7 17.5 11 27.5
GTOG24-4 Shown
Open Top Burner Models
