Part Number STH038 5/12 177
Refrigeration Tubing Schematics
X
RECEIVER
(WATER COOLED ONLY)
DRIER
COMPRESSOR
STRAINER
CONDENSER
AIR OR WATER
HOT GAS SOLENOID VALVE
EXPANSION
VALVE
EVAPORATOR
HEAT
EXCHANGER
T1 Thermistor
T4 Thermistor
T3 Thermistor
T2 Thermistor
