Manitowoc I0320

Part Number STH038 5/12 21
Clearance Requirements
Ice Machine Heat of Rejection
I0320 Self-Contained Air-Cooled
Top/Sides 305 mm
Back 127 mm
I0500
Self-Contained Air-Cooled
Top/Sides 203 mm
Back 127 mm
Series Ice
Machine
Heat of Rejection
Air
Conditioning*
Peak
I0320 3800 6000
I0500 6100 6900
*BTU/Hour
Because the heat of rejection varies during the ice making
cycle, the figure shown is an average.
