20 Part Number STH038 5/12
Location of Ice Machine
The location selected for the ice machine must meet
the following criteria. If any of these criteria are not
met, select another location.
• The location must be free of airborne and other
contaminants.
• Air temperature - Minimum 1.6°C maximum 43°C.
• Ice Making Water Inlet - Water Pressure must be
at least 1.38 bar, but must not exceed 5.52 bar.
• The location must not be near heat-generating
equipment or in direct sunlight and protected from
weather.
• The location must not obstruct air flow through or
around the ice machine. Refer to chart for
clearance requirements.
• The ice machine must be protected if it will be
subjected to temperatures below 0°C. Failure
caused by exposure to freezing temperatures is
not covered by the warranty. See “Removal from
Service/Winterization”.
Do not obstruct machine vents or openings.
