Manitowoc Indigo NXT IDT0300A User Manual

Part Number 000014141 Rev 11 12/23 15
Section 2 Installation
Clearance Requirements
AIR/WATER/REMOTE MODELS
IT0300
Self-
Contained
Air-Cooled
Water-Cooled
Top/Sides 16" (40 cm) 8" (20 cm)
Back 5" (13 cm) 5" (13 cm)
IP0320 IT0420
IT0620
Self-
Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top/Sides 12" (31 cm) 8" (20 cm)
Back 5" (13 cm) 5" (13 cm)
IT0450 IT0500
IF0500 IP0500
IF0600 IT0750
IF0900 IT0900
Self-
Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top/Sides 8" (20 cm) 8" (20 cm)
Back 5" (13 cm) 5" (13 cm)
NOTE: Top air discharge kits require the
same clearance requirements as the
comparable self-contained air-cooled
model.
IT1200 60 Hz
Self-
Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top/Sides 8" (20 cm) 8" (20 cm)
Back 5" (13 cm) 5" (13 cm)
IT1200 50 Hz
Self-
Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top 12" (31 cm) 8" (20 cm)
Sides 23" (58 cm) 8" (20 cm)
Back 8" (20 cm) 5" (13 cm)
IT1500
Self-Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top 12" (31 cm) 8" (20 cm)
Sides 8" (20 cm) 8" (20 cm)
Back 12" (31 cm) 5" (13 cm)
IT1900
Self-Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top/Sides 24" (61 cm) 8" (20 cm)
Back 12" (31 cm) 5" (13 cm)
Bristol Compressor
IT1900
Self-Contained
Air-Cooled
Water-Cooled
or Remote
Condenser
Top/Sides 8" (20 cm) 8" (20 cm)
Back 5" (13 cm) 5" (13 cm)
Copeland Compressor
REMOTE CONDENSOR MODELS
Model Top Sides* Bottom
JCF0500
JCT0500
JCF0900
JCT0900
JCT1200
JCT1500
36”
(91 cm)
24”
(61 cm)
16"
(41 cm)
* Minimum of two sides.
Notice
Condensers must be mounted horizontally
with the fan motor on top with nothing
obstructing it.
